Outback 2000Watt 12Volt 100Amp Inverter Charger - FX2012
The Outback FX2012 is a modular "building block sine wave inverter/charger that can be used for both small and large power systems. The OutBack FX2012 inverter/charger is a complete power conversion system - DC to AC inverter, battery charger and AC transfer switch. Additional FX inverter/chargers can be connected at any time in either parallel, or three-phase configurations. The OutBack FX2012 is designed to survive harsh environments anywhere in the world. Our unique sealed, gasketed die-cast aluminium chassis protects and keeps the power conversion components cool - without requiring outside air to be blown through the sensitive electronics. This reduces the major causes of inverter failure - corrosion, dust, insect and animal damage.
OutBack Power Systems is an engineer-owned, customer focused, power systems equipment manufacturer. Our engineers all have decades of power conversion design and equipment installation experience. We share a passion for leading the industry into a new era of balance of systems equipment performance, ease of use, and standardization. Our mission is to be a leading manufacturer of power electronic products for renewable energy, back-up power and vehicle applications. The goals for OutBack Power Systems is to offer high value product with the best possible performance while operating reliably in severe environmental conditions. OutBack Power System's goal is also to support our customers and their applications with an exceptional level of technical support and customer service.
Warranty
- Two years standard warranty, plus optional 5 Year Extended Warranty
Technical Specifications
Continuous Power Rating at 25 degrees C | 2000VA |
Nominal DC Input Voltage | 12 |
Nominal AC Input Voltage/Frequency | 230V / 50Hz |
Continuous AC RMS Output current at 25 degrees C | 8.7amps |
Idle Power(typical at no AV load) (Sleep - 3 watts) | 18-20 Watts |
Efficiency (typical at 25 degrees C and 75% resistive load) | >90% |
Total Harmonic distortion voltage (typical / max) | 2% / 5% |
Output Voltage Regulation
| +/- 2% typ
|
Surge Power Capability Peak (1mSec)
| 28 amps AC
|
Surge Power Capability RMS (100mSec)
| 20 amps AC
|
Overload Capability (from 25 C start) 5 second
| 4000 VA
|
Overload Capability (from 25 C start) 30 minutes
| 2500 VA
|
Automatic AC transfer Relay (at nominal AC)
| 30 amps AC
|
AC Input Current (adjustable limits)
| 30 amps max
|
AC Input Voltage Range (adjustable limits)
| 200-260 VAC
|
Frequency Range AC Input
| 40 to 60 Hz
|
DC Input Range (adjustable low battery cutout)
| 10 - 16.5 VDC
|
Recommended DC Breaker
| OBDC-250
|
Continuous Battery Charger Output amps DC
| 100 amps
|
Shipping Weight
| 27 kg
|
Quality and Safety
- Non-volatile memory
- High Surge Power
- Safety Instructions
Downloads and Manuals
Wiring Diagrams
- PS1 Wiring Diagram
- VFX3624 21.6kW 6 stack
- PS2 w/ 1 FX and X-240 as Generator Balancing
- FX 10 Stack wiring diagram
- FX 6KW Grid-Tie w/MX Stacked Wiring Diagram
- Single FX PS2 System w/MX60
- FX2000 4-7KW Parallel Stacked Wiring Diagram
- FX2000 4-7KW Series Stacked Wiring Diagram
- FX2000 8-14KW Parallel Stacked Wiring Diagram
- FX2000 8-14KW Series Stacked Wiring Diagram
- FX2000 16KW Parallel Stacked Block Diagram
- 120/240VAC 60 amp bypass for 2SW or 4FX inverters using QOU breakers
- Two AC-IOB-60 in a PSAC Wiring Diagram
- AC-IOB-60D Wiring Diagram
- AC-IOB-60 AC Bypass Wiring Diagram
- 120/240 VAC Input/Output Bypass
- X-240 Step Up/Step Down Wiring Diagram
- PS2AC & DC Wiring Diagram
- PSSB Wiring Diagram
- Quad Bypass Wiring Diagram
- Cabin, RV, or Boat with solar
- Hakalau National Wildlife Refuge
- Cabo San Lucas Quad Stack Install
Details
- Model: FX2012
- Shipping Weight: 28.4kg
- Manufacturer:
Outback Power Systems
